Today I found out twelve ways to remove a stripped screw. We’ve all been there; trying to void a warranty or otherwise take something apart and you go to take that one last screw off and invariably it strips. Now what? You can either A: Think Hammer… really, really big hammer; or B: Read the list below and pick the method that seems easiest to you on how to remove a stripped screw or bolt.
- Have a Dremel or equivalent tool? Use the Dremel to cut a notch in the screw head. Now take a flat-head screw driver and try and unscrew it using the notch you created.
- If you happen to have a drill and some drill bits handy, drill a small hole in the center of the screw. No need to drill too deep. The idea here is just to drill a small hole to allow your Phillips (cross head) screw driver to seat deeper in the hole to help it catch better when you turn it.
- If you happen to have an “easy-out” screw extractor, this is by far the easiest method. Works pretty much every time and with very little effort. They aren’t that expensive and will save you loads of time messing with stripped screws in the future.
- Use JB Weld or equivalently super strong “welding” adhesive to attach a nut to the screw head. Pick a nut that is about the same size as the screw head or at the least such that the diameter of the hole in the middle of the nut is smaller than the diameter of the hole in the screw. Now place the nut centered on top of the screw. Fill the hole with JB weld, being careful to not let it run everywhere. If the nut is flush on the screw, this shouldn’t be a problem. If it can’t be flush, use some sort of quick drying temporary gasket or the like to seal around the edges so that the JB weld doesn’t get everywhere, but rather just stays in the hole. Now let it dry the recommended time. Once it has hardened up, use a socket wrench on the attached nut to remove the screw.
Got a sufficiently wide rubber-band handy? Place it on top of the screw head then try to unscrew the screw slowly pushing really hard. Sometimes the rubber will give you the extra grip needed to get that screw out.- If you are handy at welding and don’t want to wait for the JB Weld to harden, take a nut and place it on the screw then weld the nut to the screw by welding along the inner part of the nut. Now simply remove as in #5 with a socket wrench.
- If you’ve gotten the screw partially up and the head is exposed, get a pair of needle-nose clamping pliers or at the least try a pair of non-clamping needle-nose pliers. Many a time my trusty needle-nose clamping pliers have got me out of a “stripped screw” situation.
- A slightly more risky method is to carefully drill the head off the screw. Try not to drill deeply, you just want to take the head off enough to be able to remove whatever piece you are trying to remove. Once the head is off and the piece is removed, enough of the shaft of the screw should be exposed (assuming you didn’t drill it too deep); now use needle-nose pliers to get the shaft of the screw out.
-
One of the simplest things to do is if it is a Phillips (cross head) screw, take an appropriately sized flat-head screw driver and, pushing as hard as you can, attempt to remove the screw this way. Often there is plenty of grip available for a flat-head screw driver of the right size in a stripped cross-head screw. If this doesn’t work, combine this method with the rubber band method in step 1.
- Another simple method is to use a Phillips screw driver that is slightly too big for the hole. Push down hard and tilt the Phillips at a slight angle and turn. For a minorly stripped screw, this often works.
- Depending on how fragile the thing you are working on is, you can also try taking a hammer and tapping your screw driver into the screw. If the metal was soft enough to strip in the first place, you will often be able to hammer the screwdriver into the screw head enough to give it a firm position for unscrewing. Obviously this method is no good if what you are working on is fragile.
- If you’ve gotten here and none of the above has worked, it may be time to get out your trusty old over-sized hammer and simply kill the screw… Kill it dead. Collateral damage to the thing you are working on be damned!
Sources:
- How to remove a stripped screw or bolt
- How to remove a stripped screw.
- Removing a stripped screw.
- How to remove a stripped screw with an extractor
- Screw/Rubber-band Image Courtesy of Apartmenttherapy.com
<div class=”ad-right”><!– wp_ad_camp_1 –></div>
one can purchase a “left twist drill bit” which very often will, when drilling out the screw cause the screw to come out before you need the extractor
There’s a tool called an impact driver. It works best if you use it before you strip the screw but the down-force of the hammer blow happens at exactly the same time as the driver tries to turn and often the combined shock moves a reluctant screw.
Just want to say your step #1 is awesome – worked for me the first time. thanks!!
After trying several methods, no. 12 worked just fine. As an added bonus, I got to learn how to repair sheetrock.
Hey guys I just want to let you know that the rubber band did not help with my totally stripped out tiny iphone screws. I’ve also tried JBWELD glue Eproxy. But let me back up, my first helpless trial was indeed rubber band, why not its free lying around the house. Second I tried my drill bits since I though it would be the same as drumel? Not good, got the gut to hammer it with screw driver, nope not working. So I went to Acehardware store know some of the ideas will not work, I’d ended up buying just about $40 worth. This include Screw Extractor, JBWELD glue, finally Drumel. I tried all three in this order and guess what, drumel works!! Thanks, I should have tried it first but oh well, now I know….
Your step 5 with the rubber band worked perfect, thank you!
…and the next 12 ideas are…?
Here’s one that just worked for me. Take wire cutters and use them to put grooves in the side of the head. Keep the wire cutters in the grooves and turn enough to unstick the screw.
The welding idea is not the best option for removing studs and screws unless you remove any coatings the metal may have on it (I.E. zinc, nickel etc). If you don’t remove these metals they will contaminate your weld.
Also, welding changed the temper of the metal. usually this will make the metal around the weld softer and decreasing its tensile strength. The metal needs to be heat treated to give it a high tensile strength.
I recommend Dremeling.
I read this great article and use a combo of the concepts. I filed the round head flat on two sides and used a small socket over the screwhead to remove the screw.
Ref #5: I did happen to have a sufficiently wide rubber-band that I had just removed from a bunch of asparagus. It worked beautifully with the first turn. I will keep the rest of the 12 steps in mind in case I run into one a screw that is not so giving. Thanks
