Why are There No B Batteries?

Daven Hiskey 6
Christine asks:  Where are all the B batteries?  There’s A’s (AA and AAA), no B, then C, and then D.  Why did they skip a letter?

Now You KnowThere actually are B batteries, but they aren’t something you’ll usually see stocked at most stores any longer.  Since the invention of the battery there have been a pretty amazingly diverse number of battery types used with different sizes/shapes/voltages/storage capacities/etc., and also named a variety of things.   This gave rise to the need for an industry wide standard, particularly as the lack of an international or even national standard during WWI was problematic for the military.

As such, after WWI, the War Industries Board and several other government agencies got together to try to come up with standard specifications for batteries.  A few years later, in 1928, the American Standards Association, the predecessor to the American National Standards Institute (ANSI), officially adopted this proposal, introducing  a list of battery cell sizes and their corresponding label.  For these labels, they used the suggested convention that A would be the smallest and as you went up in the letters, the batteries would get larger in size.  There also was a “No. 6″ battery that was the largest and which was just adopted as it had previously been one of the most popular battery cell sizes used (a 6 inch battery), so it was grandfathered in, though now given more strict guidelines to its exact specifications.  Others came along later, such as the AAA size which wasn’t adopted into the standard until 1959.  The ANSI standard for batteries has been revised numerous times over the years as battery technology evolves, but that’s where the designations come from.

Why it appears there is no B (or A, F, etc.) anymore is simply because those particular battery sizes never really caught on commercially, at least on the consumer end of things.  The ones that were most popular just ended up being the AA, AAA, C, and D.  Now-a-days, because those are the most commonly available to consumers, most manufactures continue to use those battery types over the many other sizes that are available to power their devices.  However, B batteries are still made and sold and pack a decent punch for their size, 21.5 mm x 60 mm (.8464 in. by 2.36 in.), producing 1.5 volts and 8350 mAh for the alkaline variety (for reference standard alkaline AA’s ring in at 1.5 volts and 2700 mAh).   ‘A’ batteries are also still in production,  last most commonly used in early-model laptop battery packs.  F batteries, on the other hand, are still used commonly in something you can find at a local store, within the rectangular 6 volt batteries.

You’ll sometimes hear that B batteries are no longer seen because they were primarily used in devices that used vacuum tubes (most commonly radios), specifically used as a battery to provide the plate voltage for the vacuum tube.  Thus, as tube radios aren’t too common anymore, the need for B batteries went away with them.  This isn’t quite accurate.  The B battery in the ANSI standard does not have the same specifications as the ‘B’ battery used with vacuum tubes.  The ‘B’ battery in this case can refer to any single or group of cells used to give the plate a positive charge in order to draw the electrons from the filament.  The voltage for these ‘B’ batteries first started out often needing 120 volts, then later typically needing 90, 67.5, 45, and 22.5 (the value kept going down as tubes gradually became more efficient over time).  Certainly actual ANSI standard ‘B’ batteries could be combined and used for this type of application, but really any battery or group of cells worked and would still be called a ‘B’ battery in this context, thanks to the naming convention adopted for this use (A, B, and C, which specified what the battery was used for in the device, rather than the ANSI standard battery specification).
